Pepperl+Fuchs Inductive sensor NCN8-18GM40-Z0

Inductive sensor NCN8-18GM40-Z0

Pepperl+Fuchs Inductive sensor NCN8-18GM40-Z0

Features
Comfort series
8 mm non-flush
2-wire DC

General specifications

Pepperl+Fuchs Inductive sensor NCN8-18GM40-Z0

Switching function Normally open (NO)
Output type Two-wire
Rated operating distance 8 mm
Installation non-flush
Output polarity DC
Assured operating distance 0 ... 6.5 mm
Actual operating distance 7.2 ... 8.8 mm typ. 8 mm
Reduction factor rAl 0.44
Reduction factor rCu 0.4
Reduction factor r304 0.7
Output type 2-wire
Nominal ratings
Operating voltage 5 ... 60 V
Switching frequency 0 ... 300 Hz
Hysteresis 1 ... 10 typ. 5 %
Reverse polarity protection reverse polarity tolerant
Short-circuit protection pulsing
Voltage drop ≤ 5 V
Operating current 2 ... 100 mA
Lowest operating current 2 mA
Off-state current 0 ... 0.5 mA typ.
Switching state indicator all direction LED, yellow
