Pepperl+Fuchs Inductive sensor NJ5-11-N-5M

Features
Comfort series
5 mm non-flush
Usable up to SIL 2 acc. to IEC 61508

General specifications

Pepperl+Fuchs Inductive sensor NJ5-11-N-5M

Switching function Normally closed (NC)
Output type NAMUR
Rated operating distance 5 mm
Installation non-flush
Assured operating distance 0 ... 4.05 mm
Reduction factor rAl 0.4
Reduction factor rCu 0.3
Reduction factor r304 0.85
Output type 2-wire
Nominal ratings
Nominal voltage 8 V
Switching frequency 0 ... 3000 Hz
Hysteresis typ. %
Suitable for 2:1 technology yes , Reverse polarity protection diode not required
Current consumption
Measuring plate not detected min. 3 mA
Measuring plate detected ≤ 1 mA
Functional safety related parameters
MTTFd 11774 a
Mission Time (TM) 20 a
Diagnostic Coverage (DC) 0 %
