Pepperl+Fuchs Inductive sensor NBN4-12GM50-E2-12M

Inductive sensor NBN4-12GM50-E2-12M

Pepperl+Fuchs Inductive sensor NBN4-12GM50-E2-12M

Features
4 mm non-flush

General specifications

Pepperl+Fuchs Inductive sensor NBN4-12GM50-E2-12M

Switching function Normally open (NO)
Output type PNP
Rated operating distance 4 mm
Installation non-flush
Output polarity DC
Assured operating distance 0 ... 3.24 mm
Reduction factor rAl 0.5
Reduction factor rCu 0.4
Reduction factor r304 0.8
Nominal ratings
Operating voltage 10 ... 30 V
Switching frequency 0 ... 1200 Hz
Reverse polarity protection reverse polarity protected
Short-circuit protection pulsing
Voltage drop ≤ 3 V
Operating current 0 ... 200 mA
Off-state current 0 ... 0.5 mA typ. 0.1 µA at 25 °C
No-load supply current ≤ 17 mA
Switching state indicator LED, yellow
Functional safety related parameters
MTTFd 990 a
Mission Time (TM) 20 a
Diagnostic Coverage (DC) 0 %
