Pepperl+Fuchs Inductive sensor NBB1,5-8GM40-Z1

Inductive sensor NBB1,5-8GM40-Z1

Pepperl+Fuchs Inductive sensor NBB1,5-8GM40-Z1

Features
1.5 mm flush
2-wire DC

General specifications

Pepperl+Fuchs Inductive sensor NBB1,5-8GM40-Z1

Switching function Normally closed (NC)
Output type Two-wire
Rated operating distance 1.5 mm
Installation flush
Output polarity DC
Assured operating distance 0 ... 1.21 mm
Actual operating distance 1.35 ... 1.65 mm typ.
Reduction factor rAl 0.22
Reduction factor rCu 0.16
Reduction factor r304 0.64
Nominal ratings
Operating voltage 5 ... 60 V
Switching frequency 0 ... 1200 Hz
Hysteresis 1 ... 10 typ. 5 %
Reverse polarity protection reverse polarity tolerant
Short-circuit protection pulsing
Voltage drop ≤ 5 V
Operating current 2 ... 100 mA
Lowest operating current 2 mA
Off-state current 0 ... 0.5 mA typ.

Switching state indicator LED, yellow
