Pepperl+Fuchs Inductive sensor NJ5-30GK-S1N

NJ5-30GK-S1N

Pepperl+Fuchs Inductive sensor NJ5-30GK-S1N

Features
Nonferrous targets
5 mm flush in ST37 / 1.0037
Usable up to SIL 3 acc. to IEC 61508
ATEX approval Ex-i and Ex-nA/tc for zone 0-2 and zone 20-22
Degree of protection IP68

General specifications

Pepperl+Fuchs Inductive sensor NJ5-30GK-S1N

Switching function Normally open (NO)
Output type NAMUR with safety function
Rated operating distance 5 mm
Installation flush in mild steel
Assured operating distance 0 ... 4.05 mm
Reduction factor rAl 1
Reduction factor rCu 1
Reduction factor r304 0
Safety Integrity Level (SIL) up to SIL3 acc. to IEC 61508 Danger! In safety-related applications the sensor must be operated with a qualified fail safe interface from Pepperl+Fuchs, such as KFD2-SH-EX1.
Consider the "exida Functional Safety Assessment" document which is available on www.pepperl-fuchs.com as an integral part of this product's documentation.
Output type 2-wire
Nominal ratings
Nominal voltage 8.2 V
Switching frequency 0 ... 150 Hz
Suitable for 2:1 technology yes , with reverse polarity protection diode
Current consumption
Measuring plate not detected ≤ 1 mA
Measuring plate detected ≥ 3 mA
