Pepperl+Fuchs Inductive sensor NJ1,5-18GM-N-D-V1

NJ1,5-18GM-N-D-V1

Pepperl+Fuchs Inductive sensor NJ1,5-18GM-N-D-V1

Features
1.5 mm flush
Compression proof up to 350 bar,
dynamic on active surface

Usable up to SIL 2 acc. to IEC 61508

Pepperl+Fuchs Inductive sensor NJ1,5-18GM-N-D-V1

General specifications
Switching function Normally closed (NC)
Output type NAMUR
Rated operating distance 1.5 mm
Installation flush
Assured operating distance 0 ... 1.22 mm
Reduction factor rAl 0
Reduction factor rCu 0
Reduction factor r304 0.55
Output type 2-wire
Nominal ratings
Nominal voltage 8.2 V (Ri approx. 1 kΩ)
Switching frequency 0 ... 400 Hz
Hysteresis typ. %
Current consumption
Measuring plate not detected min. 3 mA

Measuring plate detected ≤ 1 mA

Pepperl+Fuchs Inductive sensor NJ1,5-18GM-N-D-V1
