Pepperl+Fuchs isolated barrier KCD2-SCD-Ex1

SMART Current Driver KCD2-SCD-Ex1

Pepperl+Fuchs isolated barrier KCD2-SCD-Ex1

Features
• 1-channel isolated barrier
• 24 V DC supply (Power Rail)
• Current output up to 650 Ω load
• HART I/P and valve positioner
• Lead breakage monitoring
• Accuracy 0.1 %
• Housing width 12.5 mm
• Up to SIL 2 acc. to IEC 61508

Pepperl+Fuchs isolated barrier KCD2-SCD-Ex1

Pepperl+Fuchs isolated barrier KCD2-SCD-Ex1

Function
This isolated barrier KCD2-SCD-Ex1 is used for intrinsic safety applications. It drives SMART I/P converters, electrical valves, and positioners in hazardous areas. Digital signals are superimposed on the analog values at the field or control side and are transferred bi-directionally. Pepperl+Fuchs isolated barrier KCD2-SCD-Ex1
Current transferred across the DC/DC converter is repeated at terminals 1 and 2. An open field circuit presents a high input impedance to the
control side to allow lead breakage monitoring by control system.Pepperl+Fuchs isolated barrier KCD2-SCD-Ex1
If the loop resistance for the digital communication is too low, an internal resistor of 250 Ω between terminals 6 and 8 is available, which may be used as the HART communication resistor.
Sockets for the connection of a HART communicator are integrated into the terminals of the device
Pepperl+Fuchs isolated barrier KCD2-SCD-Ex1\
