Pepperl+Fuchs isolated barrier KCD2-STC-EX1

SMART Transmitter Power Supply KCD2-STC-EX1

Pepperl+Fuchs isolated barrier KCD2-STC-EX1

Features
• 1-channel isolated barrier
• 24 V DC supply (Power Rail)
• Input for 2-wire SMART transmitters and current sources
• Output for 4 mA ... 20 mA or 1 V ... 5 V
• Sink or source mode
• Housing width 12.5 mm
• Up to SIL 2 acc. to IEC 61508

Pepperl+Fuchs isolated barrier KCD2-STC-EX1

Pepperl+Fuchs isolated barrier KCD2-STC-EX1

Function
This isolated barrier KCD2-STC-EX1 is used for intrinsic safety applications. The device supplies 2-wire SMART transmitters in a hazardous area, and can also be used with 2-wire SMART current sources.Pepperl+Fuchs isolated barrier KCD2-STC-EX1
It transfers the analog input signal to the safe area as an isolated current value.
Digital signals may be superimposed on the input signal in the hazardous or safe area and are transferred bi-directionally.
Selectable output of current source, sink mode, or voltage output is available via DIP switches.Pepperl+Fuchs isolated barrier KCD2-STC-EX1
If the HART communication resistance in the loop is too low, the internal resistance of 250 Ω between terminals 6 and 8 can be used.
Test sockets for the connection of HART communicators are integrated into the terminals of the device.
