Pepperl+Fuchs isolated barrier KFD2-WAC2-EX1.D

Strain Gauge Converter KFD2-WAC2-Ex1.D

Pepperl+Fuchs isolated barrier KFD2-WAC2-EX1.D

Features
• 1-channel isolated barrier
• 24 V DC supply (Power Rail)
• Strain gauge input (full or half bridge)
• Output 0 mA ... ± 20 mA or 0 V ... ± 10 V
• Relay contact output
• Programmable high/low alarm
• Configurable by PACTwareTM or ke ypad
• RS 485 interface
• Line fault detection (LFD)


Function
This isolated barrier KFD2-WAC2-Ex1.D is used for intrinsic safety applications. The device is used with strain gauges, load cells and resistance measuring bridges.Pepperl+Fuchs isolated barrier KFD2-WAC2-EX1.D
Designed to provide 5 V excitation voltage, this barrier’s high quality A/D converter allows it to be used with those devices requiring 10 V. Up to four 350 Ω strain gauges connected in parallel may be powered and evaluated. Pepperl+Fuchs isolated barrier KFD2-WAC2-EX1.D
The device is easily configured by the use of keypad or with the PACTware configuration software.
The current measurement for tare, zero point, and final value can be entered in this manner.
A fault is signalized by LEDs acc. to NAMUR NE44 and a separate collective error message output.
For additional information, refer to the manual and www.pepperl-fuchs.com.
