Pepperl+Fuchs isolated barrier KFD2-STC4-1.2O

SMART Transmitter Power Supply KFD2-STC4-1.2O

Pepperl+Fuchs isolated barrier KFD2-STC4-1.2O

Features
• 1-channel signal conditioner
• 24 V DC supply (Power Rail)
• Input 2-wire and 3-wire SMART transmitters and 2-wire
SMART current sources
• Signal splitter (1 input and 2 outputs)
• Dual output 0/4 mA ... 20 mA
• Terminal blocks with test sockets
• Up to SIL 3 acc. to IEC 61508


Function
This signal conditioner KFD2-STC4-1.2O provides the isolation for nonintrinsically safe applications. The device supplies 2-wire and 3-wire SMART transmitters, and can also be used with 2-wire SMART current sources.Pepperl+Fuchs isolated barrier KFD2-STC4-1.2O
It transfers the analog input signal to the safe area as two isolated current values. Digital signals may be superimposed on the input signal and are transferred bi-directionally. If the HART communication resistance in the loop is too low, the internal resistance of 250 Ω between terminals 8, 9 and 11, 12 can be used. Test sockets for the connection of HART communicators are integrated into the terminals of the device.Pepperl+Fuchs isolated barrier KFD2-STC4-1.2O


Application
The device supports the following SMART protocols:
• HART
• BRAIN
• Foxboro
