Pepperl Fuchs KFD2-SOT2-Ex2 Switch Amplifier 2-channel isolated barrier

Pepperl Fuchs KFD2-SOT2-Ex2 Switch Amplifier 2-channel isolated barrier

Pepperl fuchs KFD2-SOT2-Ex2 Switch Amplifier 2-channel isolated barrier

Features

1.2-channel isolated barrier
2.24 V DC supply (Power Rail)
3.Dry contact or NAMUR inputs
4.Passive transistor output, non-polarized
5.Line fault detection (LFD)
6.Reversible mode of operation
7.Up to SIL 2 acc. to IEC 61508

Pepperl fuchs KFD2-SOT2-Ex2 Switch Amplifier 2-channel isolated barrier

Function

This isolated barrier is used for intrinsic safety applications. It transfers digital signals (NAMUR sensors/mechanical contacts) from a hazardous area to a safe area. Each proximity sensor or switch controls a passive transistor output for the safe area load.

Pepperl fuchs KFD2-SOT2-Ex2 Switch Amplifier 2-channel isolated barrier

The normal output state can be reversed using switch S1 for channel I and switch S2 for channel II. Switch S3 enables or disables line fault detection of the field circuit. During an error condition, the transistors revert to their deenergized state and LEDs indicate the fault according to NAMUR NE44. A unique collective error messaging feature is available when used with the Power Rail system.

Pepperl fuchs KFD2-SOT2-Ex2 Switch Amplifier 2-channel isolated barrier

Large quantity of Pepperl+Fuchs Isolated Barriers K-Systems on stock
