Pepperl Fuchs KCD2-STC-EX1.2O 1-channel isolated barrier

Pepperl Fuchs KCD2-STC-EX1.2O 1-channel isolated barrier

Features

Pepperl fuchs KCD2-STC-EX1.2O 1-channel isolated barrier

• 1-channel isolated barrier
• 24 V DC supply (Power Rail)
• Input for 2-wire SMART transmitters and current sources
• Signal splitter (1 input and 2 outputs)
• Dual output 0/4 mA ... 20 mA or 0/1 V ... 5 V
• Terminal blocks with test sockets
• Up to SIL 2 acc. to IEC 61508
Pepperl fuchs KCD2-STC-EX1.2O 1-channel isolated barrier

Function

This isolated barrier is used for intrinsic safety applications.The device supplies 2-wire transmitters in the hazardous area,and can also be used with current sources.It transfers the analog input signal to the safe area as two isolated output signals.
Bi-directional communication is supported for SMART transmitters that use current modulation to transmit data and voltage modulation to receive data.

Pepperl fuchs KCD2-STC-EX1.2O 1-channel isolated barrier
The output is selected as a current source, current sink, or voltage source via switches.Test sockets for the connection of HART communicators are integrated into the terminals of the device.

Pepperl fuchs KCD2-STC-EX1.2O 1-channel isolated barrier

Large quantity of Pepperl+Fuchs Isolated Barriers K-Systems on stock
